The new DMA35N handheld digital density meter defines the state of the art of portable density measurement. Designed for use in the most demanding industrial environments, the DMA35N gives you the density, specific gravity, or % concentration of your sample. Simply press the lever on the built-in pump and within seconds, the results are shown on the large, bright display. Need to save the data for later analysis? Press a button and the measured resuIts are stored in the instrument's memory - up to 1024 data points - and can easily be transferred to a computer or printed later.

The DMA35N is the result of many years of experience, brought together in the optimal portable package. Anton Paar introduced portable density meters in 1980 and has incorporated the comments and requests of tens of thousands of customers into this new design. Based on the familiar Anton Paar harmonic oscillator technology, the DMA35N is light, weighing only 275 grams (10 ounces) so your arm won't get tired, no matter how many samples you measure. It's small, so it easily fits into hard-to-reach places without bending or stretching, and the new pump is a dream ... no bellows that split open, no squeeze bulbs to tear. Just depress the lever with your thumb! The sample is automatically pulled into the glass oscillator. To expel the measured sample, nush the lever anain and vour're done

Specifications

Measuring range
Density: 0 to 1.999 g/cm3
Temperature: 0 to 40 oC (32 to 104 oF), filling at higher temperature possible

Uncertainty of measurement
Density: ±0.001 g/cm3
Temperature: ± 0.2 oC

Repeatability
Density: ±0.0005 g/cm3
Temperature: ±0.1 oC

Resolution
Density: 0.0001 g/cm3 Temperature: 0.1 oC or 0.1 oF

Permanently stored concentration tables
^oBrix, % Alcohol, Proof, Baume, oPlato, API gravity, SG at ref. temp, % H2SO4

Data memory
1024 measuring values

Power supply
Two 1.5 V alkaline batteries (Micro LR03 AAA)

Sample volume
approx. 2 ml

Dimensions-
140x130x25 mm (5.5x5.1x1 inches)

Weight
275 g (10 ounces)

Interface
Optional RS 232 interface with infrared data port
